TOTEM M · MECHANICAL SUPPLY KITS
Diesel
PetrolThe TOTEM mechanical supply kit is suitable for the diesel and petrol supply and measurement for the own consumption vehicles.
It is composed of:
CHASSIS
- Column xassis for direct fixation in the ground without base or additional accessories
- Main body made of aluminium and stainless steel
- Head made of carbon steel
- Treatment to maximise corrosion protection
- Weatherproof
PUMP
- self-suction with self-adjusting blades
METER:
- MG-84A · mechanical of aluminium · Accuracy: ±1 %
NOZZLE:
- automatic
HOSE:
- 4 m delivery diesel hose double layer, with adapters in both ends
DIESEL
TOTEM 50M-230 V · Mechanical supply kit
27150-CF00000
- IRON-50 230 VAC self-suction with self-adjusting blades
- Flow rate: 40-50 l/min
Size and weight (approx.):
- Dim.: 460x400x1,500 mm (length x width x height)
- Weight: 50 kg
TOTEM 75M-230 V · Mechanical supply kit
27260-CF00000
- IRON-75 230 VAC self-suction with self-adjusting blades
- Flow rate: 65-70 l/min
Size and weight (approx.):
- Dim.: 460x400x1,500 mm (length x width x height)
- Weight: 50 kg
TOTEM 100M-230 V · Mechanical supply kit
27270-CF00000
- AG-100 230 VAC self-suction with self-adjusting blades
- Flow rate: 75-90 l/min
Size and weight (approx.):
- Dim.: 460x400x1,500 mm (length x width x height)
- Weight: 57 kg
PETROL
TOTEM 50M-230 V Ex · Mechanical supply kit
27170-CF00002
- IRON-50 Ex 230 VAC self-suction with self-adjusting blades
- Flow rate: 40-50 l/min
Size and weight (approx.):
- Dim.: 460x400x1,500 mm (length x width x height)
- Weight: 50 kg
TOTEM 800M-230 · Mechanical supply kit
27180-CF00003
- AG-800 Ex 230 VAC self-suction with self-adjusting blades
- Flow rate: 60-70 l/min
Size and weight (approx.):
- Dim.: 460x400x1500 mm (LxWxH)
- Weight: 59 kg
